TLL-A型立式刮刀卸料離心脫水機
Vertical
Scraper Discharge Centrifugal Dehydrator
用途：該系列離心脫水機適用于選煤廠0-13mm級末中煤的脫水，其處理能力為50-200t/h。
Application: Centrifugal dehydrators of such series apply to the dewatering of middling and tailing with particle size of 0-13mm in coal preparation plants. Their handing capacity is 50-200t/h.
技術特點：TLL—A系列立式刮刀卸料離心脫水機是TLL系列離心脫水機的改進型，它與原機型相比具有檢修方便、潤滑合理、運轉平穩(wěn)可靠等優(yōu)點。
Technical Characteristics: TLL-A vertical scraper discharge centrifugal dehydrator is the improved TLL centrifugal dehydrator. Compared with the prototype, it enjoys advantages such as easy maintenance, reasonable lubrication, as well as smooth and reliable operation.
| 型號規(guī)格 | TLL-700A | TLL-900A | TLL-1000A | TLL-1150A | |
| 入料粒度 | ` | 13-0 | 25-0 | 25-0 | 25-0 |
| 入料水分 | % | <30 | <30 | <30 | <30 |
| 處理能力 | t/h-1 | 50 | 100 | 15 | 200 |
| 產品外在水份 | % | 5-8 | 5-8 | 5-8 | 5-8 |
| 篩網(wǎng)縫隙 | mm | 0.5 | 0.5 | 0.5 | 0.5 |
| 主電機功率 | kw | 18.5 | 45 | 55 | 75 |
| 潤滑電機功率 | kw | 0.75 | 0.75 | 1.1 | 1.1 |
| 外形尺寸 | Mm | 2175×1690×1955 | 2755×2030×2320 | 3010×2250×2515 | 3270×2460×2705 |
| 質量 | kg | 3125 | 5240 | 6465 | 7770 |
